Transformer Design Principles, Third Edition

Inbunden, Engelska, 2017

Av Robert M. Del Vecchio, Bertrand Poulin, Pierre T. Feghali, Dilipkumar Shah, Rajendra Ahuja, Robert M. del Vecchio, Robert Del Vecchio

3 049 kr

Beställningsvara. Skickas inom 10-15 vardagar

Fri frakt för medlemmar vid köp för minst 249 kr.

Finns i fler format (1)

Häftad

1 359 kr

Skickas inom 10-15 vardagar

In the newest edition, the reader will learn the basics of transformer design, starting from fundamental principles and ending with advanced model simulations. The electrical, mechanical, and thermal considerations that go into the design of a transformer are discussed with useful design formulas, which are used to ensure that the transformer will operate without overheating and survive various stressful events, such as a lightning strike or a short circuit event. This new edition includes a section on how to correct the linear impedance boundary method for non-linear materials and a simpler method to calculate temperatures and flows in windings with directed flow cooling, using graph theory. It also includes a chapter on optimization with practical suggestions on achieving the lowest cost design with constraints.

Produktinformation

Utgivningsdatum2017-08-18
Mått178 x 254 x 40 mm
Vikt1 636 g
FormatInbunden
SpråkEngelska
Antal sidor596
Upplaga3
FörlagTaylor & Francis Inc
ISBN9781498787536

Tillhör följande kategorier

INTRODUCTION. MAGNETISM AND RELATED CORE ISSUES. CIRCUIT MODEL OF A TWO WINDING TRANSFORMER WITH CORE. REACTANCE AND LEAKAGE REACTANCE CALCULATIONS. PHASORS, THREE PHASE CONNECTIONS, AND SYMMETRICAL COMPONENTS. FAULT CURRENT ANALYSIS. PHASE SHIFTING AND ZIG-ZAG TRANSFORMERS. MULTI-TERMINAL THREE PHASE TRANSFORMER MODEL. RABINS’ METHOD FOR CALCULATING LEAKAGE FIELDS, INDUCTANCES, AND FORCES IN IRON CORE TRANSFORMERS, INCLUDING AIR CORE METHODS. MECHANICAL DESIGN. ELECTRIC FIELD CALCULATIONS. CAPACITANCE CALCULATIONS. VOLTAGE BREAKDOWN THEORY AND PRACTICE. HIGH VOLTAGE IMPULSE ANALYSIS AND TESTING. NO-LOAD AND LOAD LOSSES. STRAY LOSSES FROM 3D FINITE ELEMENT ANALYSIS. THERMAL DESIGN. CONSTRAINED NONLINEAR OPTIIZATION WITH APPLICATION TO TRANSFORMER DESIGN. REFERENCES. INDEX.

This book focuses on providing an understanding of the technical details of designing traditional single-phase and multiphase power transformers. In this latest edition, which still includes fundamental design equations and theory used to design power transformers, it also provides advanced modeling simulation to further optimize transformer designs. The reader will find this book very helpful for understanding transformer design theory including many practical considerations.- IEEE Electrical Insulation Magazine, March/April 2020
