Systematic Design of Analog IP Blocks

Systematic Design of Analog IP Blocks introduces a design methodology that can help to bridge the productivity gap. Two different types of designs, depending on the design challenge, have been identified: commodity IP and star IP. Each category requires a different approach to boost design productivity. Commodity IP blocks are well suited to be automated in an analog synthesis environment and provided as soft IP. The design knowledge is usually common knowledge, and reuse is high accounting for the setup time needed for the analog library. Star IP still changes as technology evolves and the design cost can only be reduced by following a systematic design approach supported by point tools to relieve the designer from error-prone, repetitive tasks, allowing him/her to focus on new ideas to push the limits of the design. To validate the presented methodologies, three different industrial-strength applications have been selected and designed accordingly.
