Radar Cross Section Measurements

Häftad, Engelska, 2012

1 979 kr

Beställningsvara. Skickas inom 10-15 vardagar. Fri frakt för medlemmar vid köp för minst 249 kr.

When another engineering building was built on the expanded campus across the street from it many years later, the old building came to be known as West Engine, to distinguish it from the new East Engine.

Produktinformation

Utgivningsdatum2012-08-04
Mått152 x 229 x 35 mm
Vikt786 g
FormatHäftad
SpråkEngelska
Antal sidor546
FörlagSpringer-Verlag New York Inc.
ISBN9781468499063

Tillhör följande kategorier

Referensverk och tvärvetenskap inom Samhalle och politik

1 Radar Cross Section Fundamentals.- 1.1 The Need for RCS Measurements.- 1.2 Electromagnetic Wave Properties.- 1.3 The Radar Range Equation.- 1.4 Radar Cross Section.- 1.5 Polarization Scattering Matrix.- 1.6 Basic Test Range Requirements.- 1.7 Summary.- 2 Instrumentation Systems.- 2.1 The CW Cancellation Radar.- 2.2 The Noncoherent Pulsed Radar.- 2.3 Coherent Radars.- 2.4 Multiband Scattering Matrix Radars.- 2.5 Digital Functions in Multiband Radars.- 2.6 Summary.- 3 Target Support Structures.- 3.1 Foam Columns.- 3.2 String Supports.- 3.3 The Metal Pylon.- 3.4 Other Structures and Techniques.- 3.5 Summary.- 4 Measurement Errors.- 4.1 Instrumentation and Sensitivity.- 4.2 Target Illumination.- 4.3 Background Contributions.- 4.4 Target—Environment Interactions.- 4.5 Summary.- 5 Calibration.- 5.1 Instrumentation Calibration.- 5.2 Calibration Scatterers with Curved Surfaces.- 5.3 Calibration Scatterers with Flat Surfaces.- 5.4 Calibration by Substitution.- 5.5 Summary.- 6 Outdoor Test Ranges.- 6.1 Ground-Plane Configuration.- 6.2 Two-Path Propagation.- 6.3 Effect of Antenna Pattern.- 6.4 Imperfectly Reflecting Ground Planes.- 6.5 Defeating the Ground Plane.- 6.6 Summary.- 7 Indoor Chambers.- 7.1 Wall Reflections.- 7.2 Chamber Configuration.- 7.3 Chamber Absorbing Materials.- 7.4 Test Chamber Evaluation.- 7.5 Summary.- 8 Compact Ranges.- 8.1 Dielectric Lenses.- 8.2 Large Reflectors.- 8.3 Reflector Edge Configurations.- 8.4 Dual-Reflector Configurations.- 8.5 Chamber Diagnostics.- 8.6 Summary.- 9 Data Processing and Reduction.- 9.1 Statistical Measures.- 9.2 Hard-Target Characteristics.- 9.3 Display Formats.- 9.4 Background Subtraction.- 9.5 Summary.- 10 Radar Imagery.- 10.1 Radar Imaging Principles.- 10.2 The Range Profile.- 10.3 Zero-padding and Windowing.- 10.4 TheCross-Range Profile.- 10.5 Image Formation and Diagnostics.- 10.6 Summary.- 11 Dynamic Test Ranges.- 11.1 The Instrumentation Radar.- 11.2 Dynamic Target Imaging.- 11.3 The Tracking Radar.- 11.4 Metric Data.- 11.5 Some Dynamic RCS Test Ranges.- 11.6 Summary.- 12 Scale-Model Testing.- 12.1 Scaling Laws.- 12.2 Dielectrics and Absorbers.- 12.3 Metallic Coatings and Resistive Sheets.- 12.4 A Specific Full-Scale/Scale-Model Comparison.- 12.5 Summary.- 13 Test Security.- 13.1 General Requirements.- 13.2 Target Shelters.- 13.3 Range Security.- 13.4 The Black Program.- 13.5 Summary.
