Optoelectronics & Photonics

Principles & Practices

Inbunden, Engelska, 2013

5 169 kr

Beställningsvara. Skickas inom 3-6 vardagar. Fri frakt för medlemmar vid köp för minst 249 kr.

For one-semester, undergraduate-level courses in Optoelectronics and Photonics, in the departments of electrical engineering, engineering physics, and materials science and engineering.

This text takes a fresh look at the enormous developments in electo-optic devices and associated materials.

Produktinformation

Utgivningsdatum2013-02-20
Mått10 x 10 x 10 mm
Vikt1 020 g
FormatInbunden
SpråkEngelska
Antal sidor544
Upplaga2
FörlagPearson Education
ISBN9780132151498

Tillhör följande kategorier

Maskinteknik och material inom Naturvetenskap och teknik

Chapter 1 Wave Nature of Light 3 1.1 Light Waves in a Homogeneous Medium 3 A. Plane Electromagnetic Wave 3 B. Maxwell’s Wave Equation and Diverging Waves 6 Example 1.1.1 A diverging laser beam 10 1.2 Refractive Index and Dispersion 10 Example 1.2.1 Sellmeier equation and diamond 13 Example 1.2.2 Cauchy equation and diamond 14 1.3 Group Velocity and Group Index 14 Example 1.3.1 Group velocity 17 Example 1.3.2 Group velocity and index 17 Example 1.3.3 Group and phase velocities 18 1.4 Magnetic Field, Irradiance, and Poynting Vector 18 Example 1.4.1 Electric and magnetic fields in light 21 Example 1.4.2 Power and irradiance of a Gaussian beam 21 1.5 Snell’s Law and Total Internal Reflection (TIR) 22 Example 1.5.1 Beam displacement 25 1.6 Fresnel’s Equations 26 A. Amplitude Reflection and Transmission Coefficients (r and t ) 26 B. Intensity, Reflectance, and Transmittance 32 C. Goos-Hänchen Shift and Optical Tunneling 33 Example 1.6.1 Reflection of light from a less dense medium (internal reflection) 35 Example 1.6.2 Reflection at normal incidence, and internal and external reflection 36 Example 1.6.3 Reflection and transmission at the Brewster angle 37 1.7 Antireflection Coatings and Dielectric Mirrors 38 A. Antireflection Coatings on Photodetectors and Solar Cells 38 Example 1.7.1 Antireflection coating on a photodetector 39 B. Dielectric Mirrors and Bragg Reflectors 40 Example 1.7.2 Dielectric mirror 42 1.8 Absorption of Light and Complex Refractive Index 43 Example 1.8.1 Complex refractive index of InP 46 Example 1.8.2 Reflectance of CdTe around resonance absorption 47 1.9 Temporal and Spatial Coherence 47 Example 1.9.1 Coherence length of LED light 50 1.10 Superposition and Interference of Waves 51 1.11 Multiple Interference and Optical Resonators 53 Example 1.11.1 Resonator modes and spectral width of a semiconductor Fabry–Perot cavity 57 1.12 Diffraction Principles 58 A. Fraunhofer Diffraction 58 Example 1.12.1 Resolving power of imaging systems 63 B. Diffraction Grating 64 Example 1.12.2 A reflection grating 67 Additional Topics 68 1.13 Interferometers 68 1.14 Thin Film Optics: Multiple Reflections in Thin Films 70 Example 1.14.1 Thin film optics 72 1.15 Multiple Reflections in Plates and Incoherent Waves 73 1.16 Scattering of Light 74 1.17 Photonic Crystals 76 Questions and Problems 82 Chapter 2 Dielectric Waveguides and Optical Fibers 95 2.1 Symmetric Planar Dielectric Slab Waveguide 95 A. Waveguide Condition 95 B. Single and Multimode Waveguides 100 C. TE and TM Modes 100 Example 2.1.1 Waveguide modes 101 Example 2.1.2 V-number and the number of modes 102 Example 2.1.3 Mode field width, 2wo 103 2.2 Modal and Waveguide Dispersion in Planar Waveguides 104 A. Waveguide Dispersion Diagram and Group Velocity 104 B. Intermodal Dispersion 105 C. Intramodal Dispersion 106 2.3 Step-Index Optical Fiber 107 A. Principles and Allowed Modes 107 Example 2.3.1 A multimode fiber 112 Example 2.3.2 A single-mode fiber 112 B. Mode Field Diameter 112 Example 2.3.3 Mode field diameter 113 C. Propagation Constant and Group Velocity 114 Example 2.3.4 Group velocity and delay 115 D. Modal Dispersion in Multimode Step-Index Fibers 116 Example 2.3.5 A multimode fiber and dispersion 116 2.4 Numerical Aperture 117 Example 2.4.1 A multimode fiber and total acceptance angle 118 Example 2.4.2 A single-mode fiber 118 2.5 Dispersion In Single-Mode Fibers 119 A. Material Dispersion 119 B. Waveguide Dispersion 120 C. Chromatic Dispersion 122 D. Profile and Polarization Dispersion Effects 122 Example 2.5.1 Material dispersion 124 Example 2.5.2 Material, waveguide, and chromatic dispersion 125 Example 2.5.3 Chromatic dispersion at different wavelengths 125 Example 2.5.4 Waveguide dispersion 126 2.6 Dispersion Modified Fibers and Compensation 126 A. Dispersion Modified Fibers 126 B. Dispersion Compensation 128 Example 2.6.1 Dispersion compensation 130 2.7 Bit Rate, Dispersion, and Electrical and Optical Bandwidth 130 A. Bit Rate and Dispersion 130 B. Optical and Electrical Bandwidth 133 Example 2.7.1 Bit rate and dispersion for a single-mode fiber 135 2.8 The Graded Index (GRIN) Optical Fiber 135 A. Basic Properties of GRIN Fibers 135 B. Telecommunications 139 Example 2.8.1 Dispersion in a graded index fiber and bit rate 140 Example 2.8.2 Dispersion in a graded index fiber and bit rate 141 2.9 Attenuation in Optical Fibers 142 A. Attenuation Coefficient and Optical Power Levels 142 Example 2.9.1 Attenuation along an optical fiber 144 B. Intrinsic Attenuation in Optical Fibers 144 C. Intrinsic Attenuation Equations 146 Example 2.9.2 Rayleigh scattering equations 147 D. Bending losses 148 Example 2.9.3 Bending loss for SMF 151 2.10 Fiber Manufacture 152 A. Fiber Drawing 152 B. Outside Vapor Deposition 153 Example 2.10.1 Fiber drawing 155 Additional Topics 155 2.11 Wavelength Division Multiplexing: WDM 155 2.12 Nonlinear Effects in Optical Fibers and DWDM 157 2.13 Bragg Fibers 159 2.14 Photonic Crystal Fibers—Holey Fibers 160 2.15 Fiber Bragg Gratings and Sensors 163 Example 2.15.1 Fiber Bragg grating at 1550 nm 167 Questions and Problems 167 Chapter 3 Semiconductor Science and Light-Emitting Diodes 179 3.1 Review of Semiconductor Concepts and Energy Bands 179 A. Energy Band Diagrams, Density of States, Fermi-Dirac Function and Metals 179 B. Energy Band Diagrams of Semiconductors 182 3.2 Semiconductor Statistics 184 3.3 Extrinsic Semiconductors 187 A. n-Type and p-Type Semiconductors 187 B. Compensation Doping 190 C. Nondegenerate and Degenerate Semiconductors 191 E. Energy Band Diagrams in an Applied Field 192 Example 3.3.1 Fermi levels in semiconductors 193 Example 3.3.2 Conductivity of n-Si 193 3.4 Direct and Indirect Bandgap Semiconductors: E-k Diagrams 194 3.5 pn Junction Principles 198 A. Open Circuit 198 B. Forward Bias and the Shockley Diode Equation 201 C. Minority Carrier Charge Stored in Forward Bias 206 D. Recombination Current and the Total Current 206 3.6 pn Junction Reverse Current 209 3.7 pn Junction Dynamic Resistance and Capacitances 211 A. Depletion Layer Capacitance 211 B. Dynamic Resistance and Diffusion Capacitance for Small Signals 213 3.8 Recombination Lifetime 214 A. Direct Recombination 214 B. Indirect Recombination 216 Example 3.8.1 A direct bandgap pn junction 216 3.9 pn Junction Band Diagram 218 A. Open Circuit 218 B. Forward and Reverse Bias 220 Example 3.9.1 The built-in voltage from the band diagram 221 3.10 Heterojunctions 222 3.11 Light-Emitting Diodes: Principles 224 A. Homojunction LEDs 224 B. Heterostructure High Intensity LEDs 226 C. Output Spectrum 228 Example 3.11.1 LED spectral linewidth 231 Example 3.11.2 LED spectral width 232 Example 3.11.3 Dependence of the emission peak and linewidth on temperature 233 3.12 Quantum Well High Intensity LEDs 233 Example 3.12.1 Energy levels in the quantum well 236 3.13 LED Materials and Structures 237 A. LED Materials 237 B. LED Structures 238 Example 3.13.1 Light extraction from a bare LED chip 241 3.14 LED Efficiencies and Luminous Flux 242 Example 3.14.1 LED efficiencies 244 Example 3.14.2 LED brightness 245 3.15 Basic LED Characteristics 245 3.16 LEDs for Optical Fiber Communications 246 3.17 Phosphors and White LEDs 249 Additional Topics 251 3.18 LED Electronics 251 Questions and Problems 254 Chapter 4 Stimulated Emission Devices: Optical Amplifiers and Lasers 265 4.1 Stimulated Emission, Photon Amplification, and Lasers 265 A. Stimulated Emission and Population Inversion 265 B. Photon Amplification and Laser Principles 266 C. Four-Level Laser System 269 4.2 Stimulated Emission Rate and Emission Cross-Section 270 A. Stimulated Emission and Einstein Coefficients 270 Example 4.2.1 Minimum pumping power for three-level laser systems 272 B. Emission and Absorption Cross-Sections 273 Example 4.2.2 Gain coefficient in a Nd3
