Microwave and Millimeter-wave Antenna Design for 5G Smartphone Applications

Inbunden, Engelska, 2022

1 909 kr

Beställningsvara. Skickas inom 5-8 vardagar. Fri frakt för medlemmar vid köp för minst 249 kr.

Microwave and Millimeter-wave Antenna Design for 5G Smartphone Applications In-depth and practical coverage of design considerations for 5G antennas In Microwave and Millimeter-wave Antenna Design for 5G Smartphone Applications, two distinguished researchers deliver a holistic, multidisciplinary approach to antenna design methodologies. The book covers approaches ranging from sub-6GHz microwave to the millimeter-wave spectrum, explaining how microwave and millimeter-wave 5G antennas coexist and function, both independently and collaboratively. The book offers coverage of key considerations for designing millimeter-wave 5G antennas within space-constrained mobile devices, as well as practical concerns, like cost, fabrication yield, and heat dissipation. Readers will also find explorations of the likely future directions of 5G antenna evolution, as well as: A thorough introduction to basic concepts in 5G FR1 Band mobile antenna design, including discussions of antenna placement, element design, and topologiesComprehensive explorations of antenna feeding mechanisms and impedance matching, including chassis considerations and effectsPractical discussions of frequency tunable millimeter-wave 5G antenna-in-packageFulsome treatments of compact millimeter-wave 5G antenna solutions and millimeter-wave antenna-on-display technologies for 5G mobile devicesPerfect for antenna, microwave, communications, and radio-frequency engineers, Microwave and Millimeter-wave Antenna Design for 5G Smartphone Applications will also benefit graduate students, policymakers, regulators, and researchers with an interest in communications and antennas.

Produktinformation

Utgivningsdatum2022-12-19
Mått157 x 235 x 24 mm
Vikt758 g
FormatInbunden
SpråkEngelska
Antal sidor368
FörlagJohn Wiley & Sons Inc
ISBN9781394182428

Tillhör följande kategorier

Elektronik och kommunikationer inom Naturvetenskap och teknik

Wonbin Hong, Ph.D., holds the Mueunjae Chair Professorship in the Department of Electrical Engineering at Pohang University of Science and Technology. He obtained his Ph.D. in Electrical Engineering from the University of Michigan in the United States.Chow-Yen Desmond Sim, Ph.D., is Distinguished Professor at Feng Chia University in Taiwan. He is a Senior Member of the IEEE, a Consultant for Avary and the Technical Consultant for Securitag Assembly Group.
