ComSoc Guide to Passive Optical Networks

Stephen Weinstein, PhD, is an independent consultant (Communication Theory and Technology Consulting LLC) advising industrial clients and law firms. An IEEE Life Fellow, he invented the data-driven echo cancellation technique used in voiceband modems and pioneered the application of the Fast Fourier Transform to OFDM/DMT modulation. Yuanqiu Luo, PhD, is a staff engineer in the advanced technology department of Futurewei (Huawei) Technologies. She is a co-editor of ITU-T Recommendations G.987 and G.987.3 and a clause editor of IEEE Standard 802.1AS. A recipient of the IEEE Standards Award in 2011, Dr. Luo has authored more than forty publications. Ting Wang, PhD, is Department Head for NEC Laboratories America, Inc. Active in the IEEE Communications Society, Dr. Wang is Vice Chair of the Integrated Fiber & Wireless Technologies Committee, and is author of more than one hundred published papers.

• Preface xi 1 PON in the Access Picture 11.1 Why Passive Optical Network (PON) for the Last Mile Access?, 11.2 Services and Applications, 41.2.1 Displacement of Legacy High-Speed Access Services, 41.2.2 Internet Protocol (IP) over PON, 61.2.3 Triple Play and Quadruple Play, 61.2.4 Multimedia Conferencing and Shared Environments, 81.2.5 Backhaul Services, 81.2.6 Cloud-Based Services, 101.3 Legacy Access Technologies, 101.3.1 Hybrid Fiber-Coax (HFC) Cable Data System, 101.3.2 Digital Subscriber Line (DSL), 131.3.3 Broadband over Powerline (BoPL), 151.3.4 Broadband Wireless Access (BWA), 161.4 Fiber-Optic Access Systems, 181.4.1 PON as a Preferred Optical Access Network, 201.5 PON Deployment and Evolution, 22References, 242 PON Architecture and Components 272.1 Architectural Concepts and Alternatives, 272.1.1 Topologies, 272.1.2 Downstream and Upstream Requirements, 302.1.3 BPON, GPON, and EPON Systems, 302.1.4 Medium Access Techniques, 342.2 Passive and Active PON Components, 372.2.1 Passive Optical Coupler, 372.2.2 Splitter, 382.2.3 Arrayed Waveguide Grating (AWG), 402.2.4 Optical Line Termination (OLT), 412.2.5 ONU/ONT, 412.3 Management and Control Elements, 432.3.1 Bandwidth Allocation, 432.3.2 Quality of Service (QoS), 442.3.3 Deployment and Maintenance, 462.3.4 Problems and Troubleshooting, 47References, 503 Techniques and Standards 533.1 BPON Overview, 553.1.1 Basic Asynchronous Transfer Mode (ATM) Concepts, 563.2 The Full Service Access Network (FSAN) (ITU-T G.983) BPON Standard, 583.2.1 Downstream Transmission, 623.2.2 Upstream Transmission, 643.2.3 Management Functions, 653.2.4 Wavelength Division Multiplexing (WDM), 653.2.5 Dynamic Bandwidth Allocation (DBA), 673.2.6 Protection Switching, 673.3 GPON, 683.3.1 GPON Encapsulation Method (GEM), 693.3.2 Downstream Transmission, 703.3.3 Upstream Transmission, 723.3.4 Ranging, 733.3.5 Security, 743.4 EPON, 743.4.1 EPON Switched Ethernet, 773.4.2 1000BASE-PX10, 1000BASE-PX20, and 10G EPON PMD Types, 783.4.3 Medium Access Control (MAC), 793.4.4 Comparison of 1G EPON and GPON, 833.4.5 Service Interoperability in EPON (SIEPON), 85References, 864 Recent Advances and Looking to the Future 874.1 Interoperability, 874.1.1 Implementing 1:1 and 1:N Interoperability Testing, 894.1.2 Management and Quality-of-Service (QoS) Challenges, 914.2 Wavelength Division Multiplexed PON (WDM-PON), 914.2.1 Coarse Wavelength Division Multiplexing (CWDM)-PON and Dense Wavelength Division Multiplexing (DWDM)-PON, 934.2.2 WDM Devices, 954.3 Subcarrier PON, 974.4 Long-Reach PON, 1004.5 Optical–Wireless Integration, 1004.5.1 Architecture, 1014.5.2 Integration Modes, Benefits, and Challenges, 1034.5.3 Support of Next-Generation Cellular Mobile, 1064.5.4 The Future of Optical–Wireless Integration, 1074.6 Scaling Up PON to Much Higher Transmission Rates, 1084.7 Conclusion, 111References, 111Appendix: Excerpts from the IEEE 10 Gbps EPON Standard 802.3av-2009 115Index 183
