CMOS Current Amplifiers

This text is intended as a current-amplifier cookbook containing an extensive review of different current amplifier topologies realisable with modern CMOS integration technologies. The seldom-discussed issue of high-frequency distortion performance is derived for all reviewed amplifier topologies using as simple and intuitive mathematical methods as possible. The topologies discussed are also useful as building blocks for high-performance voltage-mode amplifiers. So the reader can apply the discussed techniques to both voltage- and current-mode analogue integrated circuit design. For the most popular open-loop current-mode amplifier, the second-generation current-conveyor (CCII), a macro model is derived that, unlike other reported macromodels, can accurately predict the common-mode behaviour in differential applications. Similarly, this model is used to describe the nonidealities of several other current-mode amplifiers. With modern low-voltage CMOS-technologies, the current-mode operational amplifier and the high-gain current-conveyor (CCII perform better than various open-loop current-amplifiers).Similarly, unlike with conventional voltage-mode operational amplifiers, the large-signal settling behaviour of these two amplifier types does not degrade as CMOS-processes are scaled down. This book contains application examples with experimental results in three different fields: instrumentation amplifiers, continuous-time analogue filters and logarithmic amplifiers. The instrumentation amplifier example shows that using unmatched off-the-self components very high CMRR can be reached even at relatively high frequencies.
