Art of Simulation Using PSPICEAnalog and Digital

Inbunden, Engelska, 1995

Av Bashir Al-Hashimi, England) Al-Hashimi, Bashir (University of Southampton, Southampton

3 239 kr

Beställningsvara. Skickas inom 7-10 vardagar

Fri frakt för medlemmar vid köp för minst 249 kr.

This comprehensive volume covers both elementary and advanced analog and digital circuit simulation using PSpice. The text includes many worked examples, circuit diagrams, tables, and code listings. It also compares practical results with those obtained from simulation.

Produktinformation

Utgivningsdatum1995-02-15
Mått156 x 234 x undefined mm
Vikt650 g
FormatInbunden
SpråkEngelska
SerieElectronic Engineering Systems
Antal sidor264
FörlagTaylor & Francis Inc
ISBN9780849378959

Tillhör följande kategorier

PrefaceIntroductionBrief History of SPICEBook StructurePSpice SyntaxSimulation HierarchyChapter SummaryReferencesCircuit Entry and Preliminary AnalysesIntroductionPassive Components DescriptionSemiconductor Components DescriptionDiode DescriptionBipolar Transistor DescriptionIndependent SourcesDC Independent SourceAC Independent SourceTransient Independent SourceOutput Options of Simulation ResultsDirect OutputsTabulated and Plotted OutputsGraphics Outputs-ProbeRunning PSpice-The Control ShellSimulation ExamplesSchematic CaptureChapter SummaryReferencesTransient and Fourier AnalysesTransient Independent SourcesExponential Independent Source (EXP)Pulse Independent Source (PULSE)Sinusoidal Independent Source (SIN)Single-Frequency Frequency-Modulated Source (SFFM)Piece-Wise Linear Independent Source (PWL)The .TRAN StatementSimulation ExamplesFourier Analysis (Text Mode)Fourier Analysis (Graphics Mode)Chapter SummaryReferencesDependent Sources (Linear and Nonlinear)Linear Dependent SourcesLinear Voltage-Controlled Voltage Source (VCVS)Linear Voltage-Controlled Current Source (VCCS)Linear Current-Controlled Current Source (CCCS)Linear Current-Controlled Voltage Source (CCVS)Polynomial Nonlinear Dependent SourcesOne-Dimensional Polynomial VCVSTwo-Dimensional Polynomial VCVSEffective Use of Dependent SourcesChapter SummaryReferencesSubcircuits and Efficient Use of PSpiceThe .PARAM StatementSubcircuitsCalling SubcircuitsComponents ScalingThe .STEP StatementChapter SummaryReferencesAnalog Device Models and LibrariesPassive ComponentsResistor ModelCapacitor ModelInductor ModelSemiconductor ModelsDiode ModelBipolar Transistor ModelOperational Amplifier ModelUsing Op-amp MacromodelsDealing with Unstable
