Antenna and EM Modeling with MATLAB Antenna Toolbox

Inbunden, Engelska, 2021

AvSergey N. Makarov,Vishwanath Iyer,Shashank Kulkarni,Steven R. Best

1 879 kr

Beställningsvara. Skickas inom 5-8 vardagar. Fri frakt för medlemmar vid köp för minst 249 kr.

ANTENNA AND EM MODELING WITH MATLAB ANTENNA TOOLBOX™ An essential text to MATLAB Antenna Toolbox™ as accessible and easy-to-use full-wave antenna modeling toolAntenna and EM Modeling with MATLAB Antenna Toolbox™ is a textbook on antennas intended for a one semester course. The core philosophy is to introduce the key antenna concepts and follow them up with full-wave modeling and optimization in the MATLAB Antenna Toolbox™. Such an approach will enable immediate testing of theoretical concepts by experimenting in software. It also provides the direct path to research work.The fundamental families of antennas — dipoles, loops, patches, and traveling wave antennas — are discussed in detail, together with the respective antenna arrays. Using antenna parameters such as impedance, reflection coefficient, efficiency, directivity, and gain, the reader is introduced to the different ways of understanding the performance of an antenna. Written for senior undergraduates, graduates as well as RF/Antenna engineers, Antenna and EM Modeling with Antenna Toolbox™ is a resource that:Provides 14 video assisted laboratories on using Antenna Toolbox™Includes approximately 50 real-world examples in antenna and array designOffers approximately 200 homework problemsProvides multiple ready-to-use standalone MATLAB® scripts

Produktinformation

Utgivningsdatum2021-06-29
Mått10 x 10 x 10 mm
Vikt454 g
FormatInbunden
SpråkEngelska
Antal sidor336
Upplaga2
FörlagJohn Wiley & Sons Inc
ISBN9781119693697

Tillhör följande kategorier

Elektronik och kommunikationer inom Naturvetenskap och teknik

SERGEY N. MAKAROV, PhD/DrSci, is a Professor in the Department of Electrical and Computer Engineering at Worcester Polytechnic Institute.VISHWANATH IYER, PhD, is a Principal Software Developer in the RF and EM group at the MathWorks, Inc.SHASHANK KULKARNI, PhD, is a Principal Software Developer and manages the EM and RF group at MathWorks India Pvt Ltd.STEVEN R. BEST, PhD, is President and Chairman of MegaWave Corporation, located in Worcester, MA.

Preface and Text Organization ixList of Notations xiiiAbout the Companion Website xv1 Antenna Circuit Model. Antenna Matching. Antenna Bandwidth 1Section 1 Lumped Circuit Model of an Antenna. Antenna Input Impedance 1Section 2 Antenna with Transmission Line. Antenna Reflection Coefficient. Antenna Matching. VSWR 182 Receiving Antenna: Received Voltage, Power, and Transmission Coefficient 31Section 1 Analytical Model for the Receiving Antenna 31Section 2 Model of a Two-Port Network for TX/RX Antennas 443 Antenna Radiation 55Section 1 Maxwell Equations and Boundary Conditions 55Section 2 Solution for Maxwell’s Equations in Terms of Electric and Magnetic Potentials 63Section 3 Antenna Radiation 71Section 4 Antenna Directivity and Gain 844 Antenna Balun. Antenna Reflector. Method of Images 101Section 1 Antenna Balun 101Section 2 Antenna Reflector 1165 Dipole Antenna Family: Broadband Antennas that Operate as Dipoles at Low Frequencies 135Section 1 Broadband Dipoles and Monopoles 135Section 2 Biconical, Wide Blade, and Vivaldi Antennas 1416 Loop Antennas 155Section 1 Loop Antenna vs. Dipole Antenna 1557 Small Antennas 171Section 1 Fundamental Limits on Antenna Bandwidth 171Section 2 Practical Antenna Matching and Tuning for a Predefined (50 Ω) Impedance 1858 Patch and PIFA Antennas 197Section 1 Patch Antennas 197Section 2 Planar Inverted F (PIFA) Antenna. Bandwidth Estimations 2199 Traveling Wave Antennas 233Section 1 Long Wire Antenna and Yagi-Uda Antenna 233Section 2 Helical and Spiral Antennas 24110 Antenna Designer Including Circularly Polarized Antennas 251Section 1 Fast Analysis and Design of Individual Antennas 251Section 2 Meaning of Circular Polarization and Proper Antenna Orientation 25911 Antenna Arrays 271Section 1 Array Types. Array Factor. Concept of a Scanning Array 271Section 2 Linear Arrays 287Section 3 Planar Arrays 303Index 317
