Analog Integrated Circuit Design by Simulation: Techniques, Tools, and Methods

Inbunden, Engelska, 2019

1 939 kr

Beställningsvara. Skickas inom 3-6 vardagar

Fri frakt för medlemmar vid köp för minst 249 kr.

Publisher's Note: Products purchased from Third Party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.

Learn the principles and practices of simulation-based analog IC design

This comprehensive textbook and on-the-job reference offers clear instruction on analog integrated circuit design using the latest simulation techniques. Ideal for graduate students and professionals alike, the book shows, step by step, how to develop and deploy integrated circuits for cutting-edge Internet of Things (IoT) and other applications. Analog Integrated Circuit Design by Simulation: Techniques, Tools, and Methods lays out practical, ready-to-apply engineering strategies. Application layer, device layer, and circuit layer IC design are covered in complete detail. You will learn how to tackle real-world design problems and avoid long cycles of trial and error.

Coverage includes:

•First-order DC response

•Unified closed-loop model

•Accurate modeling of DC response

•Frequency and step response

•Multi-pole dynamic response and stability

•Effect of external network on differential gain

•Continuous-time and discrete-time amplifiers

•MOSFET, NMOS, and PMOS characteristics

•Small-signal modeling and circuit analysis

•Resistor and capacitor design

•Current sources, sinks, and mirrors

•Basic, symmetrical, folded-cascode, and Miller OTAs

•Opamps with source-follower and common-source output stages

•Fully differential OTAs and opamps

Produktinformation

Utgivningsdatum2019-03-29
Mått218 x 274 x 35 mm
Vikt1 202 g
FormatInbunden
SpråkEngelska
Antal sidor576
FörlagMcGraw-Hill Education
ISBN9781260441451

Tillhör följande kategorier

Elektronik och kommunikationer inom Naturvetenskap och teknik

1 Preliminaries2 Application Layer2.1 Introduction2.2 First-Order DC Response2.2.1 First-Order Open-Loop DC Transfer Characteristic and Range Limitations2.2.2 DC Analysis with Virtual-Short Approximation2.3 Unified Closed-Loop Model2.3.1 A Generalized External-Network Model2.3.2 Extraction Procedures for Feedback and Input Factors2.4 Accurate Modeling of DC Response2.4.1 Open-Loop and Closed-Loop DC Transfer Functions2.4.2 DC Error2.5 Frequency Response2.5.1 Small-Signal Frequency Response2.5.2 Slew-Limited Bandwidth2.5.3 Harmonic Distortion2.6 Step Response2.6.1 Slew-Free Step Response2.6.2 Slew-Limited Step Response2.7 Multi-Pole Dynamic Response and Stability2.7.1 Two-Pole Dynamic Response2.7.2 Loop Gain, Phase Margin, and Stability2.8 Effect of External Network on Differential Gain2.9 Noise2.9.1 Power Supply Noise2.9.2 Fundamentals of Inherent Noise Analysis2.9.3 Closed-Loop Noise Analysis2.10 Fully-Differential Continuous-Time Amplifiers2.10.1 First-Order DC Response and Range Limitations2.10.2 Unified Closed-Loop Model2.10.3 Accurate Modeling of DC Response2.10.4 Frequency Response and Step Response2.10.5 Loop Gain, Differential Gain, and Noise2.11 Discrete-Time Amplifiers2.11.1 DC Analysis with Charge Conservation2.11.2 Unified Closed-Loop Model2.11.3 Accurate Modeling of DC Response2.11.4 Transient Response2.11.5 Loop-Gain Extraction2.12 Fully-Differential Discrete-Time Amplifiers2.12.1 DC Analysis with Charge Conservation2.12.2 Unified Closed-Loop Model2.12.3 Accurate Modeling of DC Response2.12.4 Transient Analysis and Loop-Gain Extraction2.13 References2.14 Exercises3 Device Layer3.1 Introduction3.2 MOSFET Basics3.2.1 Structure and Electrical Ports3.2.2 Performance Metrics and Design Variables3.3 NMOS Design Relations and Tools3.3.1 Long-Channel Models3.3.2 Threshold Voltage3.3.3 Drain-Source Saturation Voltage3.3.4 Sheet Current3.3.5 Transconductance Efficiency3.3.6 Output Resistance and Early Voltage3.4 PMOS Design Relations and Tools3.4.1 Strong-Inversion Model3.4.2 Subthreshold Model3.4.3 Threshold Voltage3.4.4 Drain-Source Saturation Voltage, Sheet Current, and Transconductance Efficiency3.4.5 Output Resistance and Early Voltage3.5 Thermal Effects3.6 Biasing and Sizing a MOSFET with Design Tools3.7 Small-Signal Modeling and Circuit Analysis3.7.1 MOSFET DC Small-Signal Model3.7.2 DC Small-Signal Circuit Analysis3.7.3 MOSFET Capacitances and High-Frequency Small-Signal Model3.8 MOSFET Noise Model3.9 MOSFET as a Switch3.9.1 Single-Device and Transmission-Gate Switch Properties3.9.2 Charge Injection and Clock Feedthrough3.10 Resistor Design3.10.1 Resistor Structures and Resistance Modeling3.10.2 Design Techniques for Accuracy and Precision3.10.3 MOSFET as a Resistor3.11 Capacitor Design3.11.1 MIM Capacitor3.11.2 MOSFET as a Capacitor3.12 References3.13 Exercises4 Circuit Layer4.1 Introduction4.2 Current Sources, Sinks, and Mirrors4.2.1 Fundamental Concepts and Performance Metrics4.2.2 Accuracy and Precision in Current Mirroring4.2.3 Basic Cascoding4.2.4 Low-Voltage Cascoding4.2.5 Regulated Cascoding4.2.6 Self-Cascoding4.3 Current and Voltage References4.3.1 Voltage-Divider Current Reference4.3.2 Beta-Multiplier Current Reference4.3.3 Bandgap Voltage Reference4.4 Basic Amplifier Stages4.4.1 Common-Source Stage4.4.2 Source Follower4.4.3 Basic Differential Pair4.4.4 Source-Degenerated Differential Pair4.4.5 Super-GM Differential Pair4.5 Basic OTA4.5.1 DC Transfer Characteristic as a Voltage Amplifier4.5.2 R
