• SPM Techniques for Electrical Characterization.- Scanning Tunneling Potentiometry: The Power of STM applied to Electrical Transport.- Probing Semiconductor Technology and Devices with Scanning Spreading Resistance Microscopy.- Scanning Capacitance Microscopy for Electrical Characterization of Semiconductors and Dielectrics.- Principles of Kelvin Probe Force Microscopy.- Frequency-Dependent Transport Imaging by Scanning Probe Microscopy.- Review of Ferroelectric Domain Imaging by Piezoresponse Force Microscopy.- Principles of Near-Field Microwave Microscopy.- Electromagnetic Singularities and Resonances in Near-Field Optical Probes.- Electrochemical SPM.- Near-Field High-Frequency Probing.- Electrical and Electromechanical Imaging at the Limits of Resolution.- Scanning Probe Microscopy on Low-Dimensional Electron Systems in III–V Semiconductors.- Spin-Polarized Scanning Tunneling Microscopy.- Scanning Probe Measurements of Electron Transport in Molecules.- Scanning Probe Microscopy of Individual Carbon Nanotube Quantum Devices.- Conductance AFM Measurements of Transport Through Nanotubes and Nanotube Networks.- Theory of Scanning Probe Microscopy.- Multi-Probe Scanning Tunneling Microscopy.- Dynamic Force Microscopy and Spectroscopy in Vacuum.- Scanning Tunneling Microscopy and Spectroscopy of Manganites.- Electrical SPM Characterization of Materials and Devices.- Scanning Voltage Microscopy.- Electrical Scanning Probe Microscopy of Biomolecules on Surfaces and at Interfaces.- Electromechanical Behavior in Biological Systems at the Nanoscale.- Scanning Capacitance Microscopy.- Kelvin Probe Force Microscopy of Semiconductors.- Nanoscale Characterization of Electronic and Electrical Properties of III-Nitrides by Scanning Probe Microscopy.- Electron Flow Through MolecularStructures.- Electrical Characterization of Perovskite Nanostructures by SPM.- SPM Measurements of Electric Properties of Organic Molecules.- High-Sensitivity Electric Force Microscopy of Organic Electronic Materials and Devices.- Electrical Nanofabrication.- Electrical SPM-Based Nanofabrication Techniques.- Fundamental Science and Lithographic Applications of Scanning Probe Oxidation.- UHV-STM Nanofabrication on Silicon.- Ferroelectric Lithography.- Patterned Self-Assembled Monolayers via Scanning Probe Lithography.- Resistive Probe Storage: Read/Write Mechanism.

From the reviews: "The stated goal of this book is 'to provide a comprehensive reference on the nanoscale characterization of electrical and mechanical properties of functional materials by SPM techniques and to make readers aware of tremendous developments in the field in the last decade.' ... The images are particularly clear even to the non-specialist eyes. ... The black and white and color figures are of good quality. The photographs are all excellent. ... will be helpful to materials scientists in universities and research centers." (Fernande Grandjean and Gary J. Long, Physicalia, Vol. 30 (2), 2008)
