Transient Analysis of Power Systems

Solution Techniques, Tools and Applications

Inbunden, Engelska, 2015

Av Juan A. Martinez-Velasco, Juan A Martinez-Velasco

1 889 kr

Beställningsvara. Skickas inom 10-15 vardagar

Fri frakt för medlemmar vid köp för minst 249 kr.

The simulation of electromagnetic transients is a mature field that plays an important role in the design of modern power systems. Since the first steps in this field to date, a significant effort has been dedicated to the development of new techniques and more powerful software tools. Sophisticated models, complex solution techniques and powerful simulation tools have been developed to perform studies that are of supreme importance in the design of modern power systems. The first developments of transients tools were mostly aimed at calculating over-voltages. Presently, these tools are applied to a myriad of studies (e.g. FACTS and Custom Power applications, protective relay performance, simulation of smart grids) for which detailed models and fast solution methods can be of paramount importance.This book provides a basic understanding of the main aspects to be considered when performing electromagnetic transients studies, detailing the main applications of present electromagnetic transients (EMT) tools, and discusses new developments for enhanced simulation capability.Key features: Provides up-to-date information on solution techniques and software capabilities for simulation of electromagnetic transients.Covers key aspects that can expand the capabilities of a transient software tool (e.g. interfacing techniques) or speed up transients simulation (e.g. dynamic model averaging).Applies EMT-type tools to a wide spectrum of studies that range from fast electromagnetic transients to slow electromechanical transients, including power electronic applications, distributed energy resources and protection systems.Illustrates the application of EMT tools to the analysis and simulation of smart grids.

Produktinformation

Utgivningsdatum2015-01-23
Mått178 x 254 x 38 mm
Vikt1 125 g
FormatInbunden
SpråkEngelska
SerieIEEE Press
Antal sidor656
FörlagJohn Wiley & Sons Inc
ISBN9781118352342

Tillhör följande kategorier

Energiteknik inom Naturvetenskap och teknik

Juan A. Martinez-Velasco received his Ingeniero Industrial and Doctor Ingeniero Industrial degrees from the Universitat Politècnica de Catalunya (UPC), Spain. He is currently with the Departament d'Enginyeria Elèctrica of the UPC where his teaching and research areas cover Power Systems Analysis, Transmission and Distribution, Power Quality and Electromagnetic Transients. He has authored and co-authored more than 200 journal and conference papers. He is also an active member of several IEEE and CIGRE Working Groups.
