Multi-Gigahertz Nyquist Analog-to-Digital Converters

Architecture and Circuit Innovations in Deep-Scaled CMOS and FinFET Technologies

Häftad, Engelska, 2024

Av Athanasios T. Ramkaj, Marcel J.M. Pelgrom, Michiel S. J. Steyaert, Filip Tavernier, Marcel J. M. Pelgrom

1 849 kr

Beställningsvara. Skickas inom 10-15 vardagar

Fri frakt för medlemmar vid köp för minst 249 kr.

Finns i fler format (1)

Inbunden

1 849 kr

Skickas inom 10-15 vardagar

This book proposes innovative circuit, architecture, and system solutions in deep-scaled CMOS and FinFET technologies, which address the challenges in maximizing the accuracy*speed/power of multi-GHz sample rate and bandwidth Analog-to-Digital Converters (ADC)s. A new holistic approach is introduced that first identifies the major error sources of a converter’ building blocks, and quantitatively analyzes their impact on the overall performance, establishing the fundamental circuit-imposed accuracy – speed – power limits. The analysis extends to the architecture level, by introducing a mathematical framework to estimate and compare the accuracy – speed – power limits of several ADC architectures and variants. To gain system-level insight, time-interleaving is covered in detail, and a framework is also introduced to compare key metrics of interleaver architectures quantitatively. The impact of technology is also considered by adding process effects from several deep-scaled CMOS technologies. The validity of the introduced analytical approach and the feasibility of the proposed concepts are demonstrated by four silicon prototype Integrated Circuits (IC)s, realized in ultra-deep-scaled CMOS and FinFET technologies.Introduces a new, holistic approach for the analysis and design of high-performance ADCs in deep-scaled CMOS technologies, from theoretical concepts to silicon bring-up and verification;Describes novel methods and techniques to push the accuracy – speed – power boundaries of multi-GHz ADCs, analyzing core and peripheral circuits’ trade-offs across the entire ADC chain;Supports the introduced analysis and design concepts by four state-of-the-art silicon prototype ICs, implemented in 28nm bulk CMOS and 16nm FinFET technologies;Provides a useful reference and a valuable tool for beginners as well as experienced ADC design engineers.

Produktinformation

Utgivningsdatum2024-01-14
Mått155 x 235 x 17 mm
Vikt452 g
FormatHäftad
SpråkEngelska
SerieAnalog Circuits and Signal Processing
Antal sidor269
FörlagSpringer International Publishing AG
ISBN9783031227110

Tillhör följande kategorier

Athanasios T. Ramkaj received the M.Sc. degree (cum laude) in electrical engineering (microelectronics) from TU Delft, Delft, The Netherlands, and the Ph.D. degree (summa cum laude) in electrical engineering from KU Leuven, Leuven, Belgium, in 2014 and 2021, respectively. Since June 2021, he has been with the Murmann Mixed-Signal Group, Stanford University, Stanford, CA USA, as a postdoctoral research fellow. In parallel, he is also a visiting researcher at Kilby Labs, Texas Instruments, Santa Clara, CA USA, investigating multi-GHz ultra-low jitter A/D solutions. From 2013 to 2014, he was an AMS research/design intern in the Central Research & Development Department of NXP Semiconductors, Eindhoven, The Netherlands, where he worked on GHz-range A/D converters for communication systems. In 2019, he was an AMS research/design intern with the High-Speed Data Converters group of Analog Devices Inc., Wilmington, MA USA, investigating highly integrated solutionsfor bandwidth extension of next generation RF A/D converters. His main research interests include high-speed/bandwidth high-resolution RF sampling A/D converters, high-speed analog/mixed-signal circuits for wireline and wireless systems, ultra-wideband receiver front ends, and ultra-low jitter clocking.Dr. Ramkaj is the recipient of the 2021 Analog Devices Outstanding Student Designer Award, the 2019-2020 IEEE Solid-State Circuits Society Predoctoral Achievement Award, and the 2015 IEEE PRIME Golden Leaf Best Student Paper Award. He also serves as a reviewer for the IEEE JOURNAL OF SOLID-STATE CIRCUITS, IEEE TRANSACTIONS ON VERY LARGE SCALE INTEGRATION SYSTEMS, IEEE TRANSACTIONS ON CIRCUITS AND SYSTEMS I: REGULAR PAPERS, and IEEE TRANSACTIONS ON CIRCUITS AND SYSTEMS II: EXPRESS BRIEFS. Marcel J. M. Pelgrom received his M.Sc. and Ph.D. degrees from Twente University, Enschede, The Netherlands. In 1979 he joined Philips Research Laboratories, wherehis research has covered topics as Charge Coupled Devices, MOS matching properties, analog-to-digital conversion, digital image correlation, and various analog building block techniques. He has headed several project teams and was as a team leader for high-speed analog-to-digital conversion products responsible for many Integrated Circuits. His IEEE JOURNAL OF SOLID-STATE CIRCUITS paper on MOS transistor mismatch is the most cited paper of this Journal. From 1996 till 2003 he was a department head for mixed-signal electronics research. In 2003 and 2014 he spent a sabbatical in Stanford University, Stanford, CA, USA, where he was appointed a consulting professor. Till 2013 he was a member of the technical staff of NXP Semiconductors, Eindhoven, The Netherlands. Next to the various activities concerning industry-academic relations, he was involved as a research fellow in research on substrate noise, variability and advanced conversion techniques. Presently, he is an independent consultant.Dr. Pelgrom is an honorary professor at the KU Leuven, Leuven, Belgium, and the 2017 recipient of the prestigious IEEE Gustav R. Kirchhoff award. He served twice as an IEEE Distinguished Lecturer, as associate editor for the IEEE TRANSACTIONS ON CIRCUITS AND SYSTEMS I: REGULAR PAPERS, and has written over 40 publications, three books, seven book chapters, and holds 37 US patents. He is currently lecturing at Twente University, Enschede, The Netherlands, Delft University, Delft, The Netherlands, and for MEAD/EPFL, Lausanne, Switzerland. Michiel S. J. Steyaert received the M.Sc. degree in electrical and mechanical engineering and the Ph.D. degree in electronics from KU Leuven, Leuven, Belgium, in 1983 and 1987, respectively. From 1983 to 1986, he received the IWNOL Fellowship from the Belgian National Foundation for Industrial Research, which allowed him to work as a Research Assistant with the Laboratory ESAT, KU Leuven. In 1987, he was responsible for several industrial projects in the field of analog micropower circuits with the Laboratory ESAT as an IWONL Project Researcher. In 1988, he was a Visiting Assistant Professor with the University of California at Los Angeles, Los Angeles, CA, USA. He was appointed by the National Fund of Scientific Research, Belgium, as a Research Associate in 1989, as a Senior Research Associate in 1992, and as a Research Director with the Laboratory ESAT, KU Leuven, in 1996. Between 1989 and 1996, he was also a part-time Associate Professor. He was the Chair of the Electrical Engineering Department from 2005 until 2012. He is currently a Full Professor with KU Leuven. He was also the Dean of the Faculty of Engineering until 2020. He authored or co-authored over 500 papers in international journals or proceedings and co-authored over 24 books. His current research interests are in high performance and high-frequency analog integrated circuits for telecommunication systems and analog signalprocessing.Dr. Steyaert received the 1990 and the 2001 European Solid-State Circuits Conference Best Paper Award, the 1991 and the 2000 NFWO Alcatel-Bell-Telephone Award for innovative work in integrated circuits for telecommunications, the 1995 and the 1997 IEEE-ISSCC Evening Session Award, and the 1999 IEEE Circuit and Systems Society Guillemin-Cauer Award. He is the only European Researcher who received both the 50th Anniversary Top ISSCC Contributors Award in 2003 and the 60th Anniversary Top ISSCC Contributors Award in 2013, for his strong and sustained contributions. Filip Tavernier obtained the M.Sc. degree in electrical engineering and the Ph.D. degree in engineering science from KU Leuven, Leuven, Belgium, in 2005 and 2011, respectively. From 2011 to 2014, he was a Senior Fellow in the Microelectronics Group at the European Organisation for Nuclear Research (CERN), Geneva, Switzerland. From 2014 to 2015, he was a Postdoctoral Researcher with the Department of Electrical Engineering ESAT-MICAS of KU Leuven. From 2015 until 2020, he was an Assistant Professor, and since 2020, he is an Associate Professor at KU Leuven within the same department. His main research interests are analog and mixed-signal integrated circuits for high-performance data converters, DC-DC converters, optical receivers, and cryogenic circuits.Prof. Tavernier is a Treasurer of the IEEE SSCS Benelux Chapter, an SSCS European Webinar Coordinator, a member of the Technical Program Committee of the European Solid State Circuits Conference (ESSCIRC) and the Custom Integrated Circuits Conference (CICC), and a member of the International Solid-State Circuits Conference (ISSCC) Student Research Preview Committee. He also serves as an Associate Editor for the IEEE SOLID-STATE CIRCUIT LETTERS.
