Capillary Forces in Microassembly

Modeling, Simulation, Experiments, and Case Study

Häftad, Engelska, 2010

Av Pierre Lambert

2 109 kr

Beställningsvara. Skickas inom 7-10 vardagar

Fri frakt för medlemmar vid köp för minst 249 kr.

Finns i fler format (1)

Inbunden

2 109 kr

Skickas inom 7-10 vardagar

Capillary Forces in Microassembly discusses the use of capillary forces as a gripping principle in microscale assembly. Clearly written and well-organized, this text brings together physical concepts at the microscale with practical applications in micromanipulation. Throughout this work, the reader will find a review of the existing gripping principles, elements to model capillary forces as well as descriptions of the simulation and experimental test bench developed to study the design parameters. Using well-known concepts from surface science (such as surface tension, capillary effects, wettability, and contact angles) as inputs to mechanical models, the amount of effort required to handle micro-components is predicted. These developments are then applied in a case study concerning the pick and place of balls in a watch ball bearing.Researchers and engineers involved in micromanipulation and precision assembly will find this a highly useful reference for microassembly system design and analysis.

Produktinformation

Utgivningsdatum2010-11-24
Mått155 x 235 x undefined mm
FormatHäftad
SpråkEngelska
SerieMicrotechnology and MEMS
Antal sidor263
FörlagSpringer-Verlag New York Inc.
ISBN9781441943828

Tillhör följande kategorier

Microassembly Specificities.- From Conventional Assembly to Microassembly.- Classification of Forces Acting in the Microworld.- Handling Principles for Microassembly.- Conclusions.- Modeling and Simulation of Capillary Forces.- First Set of Parameters.- State of the Art on the Capillary Force Models at Equilibrium.- Static Simulation at Constant Volume of Liquid.- Comparisons Between the Capillary Force Models.- Example 1: Application to the Modeling of a Microgripper for Watch Bearings.- Second Set of Parameters.- Limits of the Static Simulation.- Approaching Contact Distance, Rupture Criteria, and Volume Repartition After Separation.- Example 2: Numerical Implementation of the Proposed Models.- Conclusions of the Theoretical Study of Capillary Forces.- Experimental Aspects.- Test Bed and Characterization.- Results.- Example 3: Application to the Watch Bearing.- Example 4: Application to the Watch Bearing.- Conclusions.- General Conclusions and Perspectives.- Conclusions and Perspectives.- Appendices.- Modeling Complements.- Geometry Complements.- Comparison Between Both Approaches.- Symbols.

From the reviews:“Presented in five parts this text considers the use of capillary forces as a means to grip and assemble micrometre scale structures. … This book reads easily and is well presented in terms of technical figures and mathematical detail. … topics discussed are illustrated via a number of examples and, ultimately a thorough case study involving a watch bearing. … serves best as a reference for those specialists working in the field or for a postgraduate researcher looking for a clear explanation of microassembly principles.” (Matthew R. Foreman, Contemporary Physics, Vol. 51 (6), 2010)
